Casio SE-S400 Service Manual

– 43 –
SE-S400/SE-S800/PCR-T500/PCR-T520/SE-C450
SE-S3000/SE-S900/PCR-T2300/PCR-T2400/SE-C3500
1 SE-S400_SR
2 SE-S400_BK
3 PCR-T500
4 PCR-T520
5 SE-C450
6 SE-S3000_SR
7 SE-S3000_BK
8 PCR-T2300
9 PCR-T2400
10 SE-C3500
11 SE-S800
12 SE-S900
123456789101112
RParts NameN Code No. SpecificationItem
Q'TY
14 10317125 PLATEN ARM/R RJE502344-001V02 1 1111 1C
15 10452862 PCB ASSY/E291-1 RJE504081*001V01 1 1 1 1 1 1 A
15 10542357 PCB ASSY/E291-1 RJE504081*003 1 1 1 1 1 1 A
15 10452868 PCB ASSY/E291-1 RJE504081*002V01 1 1111 1A
15 10542358 PCB ASSY/E291-1 RJE504081*005 1 1111 1A
10225980 FUSE 230.600MXP 1 1 1 1 1 1 1 1 1 1 1 1 A
* Item No.15, 34, 34-1, 35 ,35-1
Please refer to service Bulletin No. SA-582 issued on 4th Aug. 2016 for details.
16 10294944 PCB ASSY/E292-COM RJE502628*002V01 1 1 1 1 1 1 1 1 1111A
17 63452238 SPRING/BATTERY A42606B-1 1 1 1 1 1 1 1 1 1111C
18 10294939 SPRING/BATTERY RJE502620-001V01 1 1 1 1 1 1 1 1 1111C
19 10294940 SPRING/BATTERY RJE502622-001V01 1 1 1 1 1 1 1 1 1111C
20 10282081 CONNECTOR ASSY/BATTERY RJE502392*001V02 1 1 1 1 1 1 1 1 1111C
21 10127255 CUSHION/120X6 RJE500743-001V01 1 1 1 1 1 1 1 1 1111C
22 10452919 B-CASE-SUBASSY RJE502637*005V01 1 1 1 1 1 1 C
22 10452925 B-CASE-SUBASSY RJE502637*006V03 1 1111 1C
22-1 10460652 BLIND/PLATE/SD RJE504123V01-1 111111111111C
22-2 10460808 COVER/SD RJE502602V03-3 111111111111C
22-3 10142488 ROLLER/P RJE500850-001V01 111111111111C
22-4 10236328 ROLLER/RP RJE500121V02-1 1 1111 1C
23 10292223 HOLDER/IC RJE502611-001V01 1 1 1 1 1 1 1 1 1 1 1 1 C
24 10346725 PIVOT RJE502342-002V03 1 1111 1C
S1 SCREW S-BDPT-3X8ZC 444445555545
S2 SCREW S-BDST-2X5Z3 222224444424
S3 SCREW S-FLPT-3X8ZC 222222222222
S4 SCREW S-BDST-3X8Z3 444444444444
S5 SCREW S-BDMA-3X5Z3 222222222222

Casio SE-S400 Specifications

General

Clerk lock	Yes
Types of payment	Cash
Number of Price Look-Up codes (PLUs)	3000 PLUs
Supported paper width	58 mm
Display number of lines	10 lines
Display number of characters	26
Second display number of characters	20
RS-232 ports	2
Power source	AC
AC input voltage	100-240 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	220 mm
