Casio TE-3000S Service Manual

— 10 —
4.1 Remove the screw and the earth cable.
Remove the two screws.
2 Remove the LCD ass’y.
6.Remove LCD rear case.
NOTE: Be careful of the hooks when removing the LCD rear case.
5.Remove the two screws.
1 2
Hooks
8.Remove two screws and one FPC, and then separate E466-E PCB.
7.Remove the slide knob.
