V-R100
– 14 –
E. SHAFT-SUBASSY / PS-COVER
E-1. SHAFT-SUBASSY
1. Undo four screws.
2. Dismount SHAFT-SUBASSY.
E-2. PS-COVER
1. Undo two screws.
2. Remove PS-COVER.
SHAFT-SUBASSY
PS-COVER
Screws (S7)
Screws (S7)
