‘The
VZ-10M's
graphic
display
can
be
used
in
a
number
of
functions
to
Provide
a
“graphic”
view
of
parameter
editing.
You'll
find
those
func-
tions
which
feature
graphic
editing
capabilities
marked
in
the
Function
Indexes
(see
page
20).
Naturally,
the
functions
which
can
be
edited
graphically
are
those
which
‘can
easily
be
expressed
graphically
as
“curves”
or
envelopes
-
such
as
MENU
1-03
(PITCH
ENVELOPE),
MENU
1-13
(TREMOLO),
and
MENU
2-13
(POS
CROSS
FADE).
{In
many
cases,
you
may
find
"graphic
editing”
easier
and
faster
than
“dig-
ital
editing.
Through
graphic
editing,
you
can
actually
see
-
in
real
time
-
how
changes
in
parameter
values
affect
the
display’s
graphic
representa-
tions
of
envelopes,
contours,
etc.
As
the
selected
parameter
is
altered,
the
sraphic
-
and
the
sound
-
changes.
For
most
people,
this
sort
of
editing
is
often
easier
to
understand
than
digital
editing,
where
all
you
have
to
work
with
is
“numbers”.
For
a
clearer
understanding
of
graphic
editing,
be
sure
to
go
through
the
practice
exercise
found
on
page
26.
To
use
the
graphic
editing
function
‘There
are
basically
two
points
in
the
editing
process
where
you
can
“enter”
the
graphic
editing
mode.
“Normally,
you
simply
press
the
DISPLAY
key
after
moving
to
the
‘parameter
level
in
any
function
(see
example
"A"
on
page
26).
Notice
that
the
DISPLAY
key
indicator
lights
when
in
the
graphic
editing
mode.
To
return
to
digital
(normal)
editing,
simply
press
the
DISPLAY
key
‘once
again
so
that
the
indicator
goes
out.
*
You
can
also
enter
the
graphic editing
mode
before
moving
to
the
parameter
level
of
any
function.
Simply
select
the
function
you
want
to
edit
graphically
and
press
the
DISPLAY
key
-there’s
no
need
to
press
|
MENU
key
(MENU
1
key,
MENU
2
key,
etc.)
to
“access”
the
func-
tion
parameters.
Note,
however,
that
when
you
want
to
exit
to
the
FUNC-
TION
level
of
the
display
to
choose
a
different
function,
you
must
first
tur
the
graphic
display
function
OFF
(by
pressing
the
DISPLAY
key
‘once
again,
and
then
press
a
MENU
key,
as
with
normal
digital
editing.
(Gee
example
“B”,
page
28).
To
adjust
graphic
display
brightness
‘The
VZ-10M’s
liquid
crystal
graphic
display
can
be
adjusted
to
various
degrees
of
brightness
for
clear
viewing
under
virtually
any
lighting
condi-
tion.
To
adjust
display
brightness,
hold
down
the
DISPLAY
key
and
move
the
VALUE
slider.
