— 2 —
MIDI: 16 multi-timbre receive, GM Level 1 standard
Other Functions
Pitch Bend Range: Adjustable (12 semitones upwards and downwards)
Modulation: Equipped
Transpose: 49 steps (–24 semitones to +24 semitones)
Tuning: Variable (A4 = approximately 440Hz ±100 cents)
LCD: Adjustable contrast
SMF Player: Flash memory storage for up to 200 files*
Supported Format: SMF0
Flash Memory
Capacity: 2MB
Shared Area: Approximately 1.5MB (waveform data, accompaniment data, SMF data)
Further storage of waveform, accompaniment, and SMF data becomes
impossible after the total of such data reaches approximately 1.5MB.
Card Slot 3.3V SmartMedia
TM
(8MB, 16MB, 32MB, 64MB, 128MB)
Functions: Save and load of user tones, user songs, and registration data; play-
back of SMF; card formatting; file delete; file rename
Floppy Disk Drive
Type: 3.5" FDD
Formats: 2DD (720KB MS-DOS format) / 2HD (1.44MB MS-DOS format)
Functions: Save and load of user tones, user songs, and registration data; play-
back of SMF; disk formatting; file delete; file rename
Terminals
MIDI Terminals: IN, OUT
Sustain/Assignable Terminal:
Standard jack (sustain, sostenuto, soft, rhythm start/stop)
Headphone:
Stereo standard jack
Output Impedance: 200Ω
Output Voltage: 250mV (RMS) MAX
Line Out (R, L/MONO): Standard jack × 2
Output Impedance: 3kΩ
Output Voltage: 1.5V (RMS) MAX
Power Supply: Dual power supply system
Batteries: 6 D-size batteries
Battery Life: Approximately 4 hours continuous operation on alkaline batteries
AC Adaptor: AD-12
Auto Power Off: Turns power off approximately six minutes after last key operation. En-
abled under battery power only, can be disabled manually.
Speaker Output: 6.1W + 6.1W
Power consumption: 12V 18W
Dimensions: 122.3 × 42.3 × 16.0 cm (48
3
/16 × 16
11
/16 × 6
5
/16 inch)
Weight: Approximately 10.0 kg (22.0 lbs) (without batteries)
* The same memory area is used to store waveform data, accompaniment data, and SMF data.
ELECTRICAL
Current drain with 12 V DC:
No sound output 230 mA ± 20 %
Maximum volume 1430 mA ± 20 %
with 16 keys from E1 to F3 pressed in 193 BREATHY ALTO SAX
Volume: MAX., Velocity: MAX.
Speaker output level (Vrms with 8 Ω load each channel):
with key G2 in 193 BREATHY ALTO SAX
Volume: MAX., Velocity: MAX. L/R: 5000 mV ± 20 %
Phone output level (Vrms with 8 Ω load each channel):
with key C3(L)/G2(R) in 193 BREATHY ALTO SAX
Volume: MAX., Velocity: MAX. L/R: 390 mV ± 20 %
Output level (Vrms with 47 kΩ load each channel):
with key C3(L)/G2(R) in 193 BREATHY ALTO SAX
Volume: MAX., Velocity: MAX. L/R: 3100 mV ± 20 %
