Page #17 background imageLoading...
Page #17 background image
— 15 —
10.Remove the rubber keys.
Projection
Note: Pay attention to the positions of the rubber keys as one of them has a different length.
Match the projections of the rubber keys with the holes of the lower case when reassembling.
9. Remove 24 screws and then the PCB ASSY (KY1M, KY2M).
