Casio WK-3800 Service Manual

— 24 —
N
Item
Code No. Part Name Specification QTY
Price
Code
R Remarks
Case Unit
15 10200667 COVER/BATTERY TK-M341288*003 1 AX C
N 16 10247813 PLATE/DISPLAY RJM502476-008V01 1 C
17 10197775 KNOB/ROTARY M341109-005 1 AE C
N 18 10232704 SPEAKER C12JA28 2 C
N 19 10232702 SPEAKER C05JH60 2 C
20 10197776 LCD TR4194N 1 BO C
21 10122917 PLATE/BACK LIGHT RJM502475-001V01 1 AP X
22 10122970 FILM RJM502473-001V01 1 AA X
23 10081190 PIECE/TOP RJM501982-001V01 1 AA X
24 10122965 CONNECTOR RJM502474-001V01 2 AI C
25 10200666 BENDER ASSY TK-M340804*009 1 BU C
26 10200671 BENDER ASSY TK-M340804*010 1 BS C
N 27 10247815 RUBBER/KEY/A RJM502517-008V01 2 C
N 28 10247817 RUBBER/KEY/B RJM502518-007V01 1 C
N 29 10247819 RUBBER/KEY/C RJM502519-007V01 1 C
30 10197780 RUBBER/KEY/D RJM502520-004V01 1 AD C
31 10197781 RUBBER/KEY/E RJM502521-004V01 1 AB C
N 32 10247823 RUBBER/KEY/F RJM502522-008V01 1 C
N 33 10247825 RUBBER/KEY/G RJM502523-008V01 1 C
34 10197784 RUBBER/KEY/H RJM502524-003V01 1 AV C
35 10123043 RUBBER/KEY/J RJM502525-001V01 1 AA C
N 36 10247828 RUBBER/KEY/K RJM502526-007V01 1 AD C
N 37 10247881 RUBBER/KEY/L RJM502527-007V02 1 AF C
N 38 10247887 RUBBER/KEY/M RJM502870-007V01 1 AF C
N 39 10247883 RUBBER/KEY/N RJM502529-007V01 1 AM C
N 40 10247885 RUBBER/KEY/P RJM502530-007V01 1 AB C
N 41 10248141 CASE ASSY/UPPER TK-RJM506695*001 1 X
42 10200674 CASE ASSY/MIDDLE TK-M141081*012 1 DE X
42-1 10036658 SPRING/BATTERY/(+) M441101A-1 1 AA X
42-2 10036659 SPRING/BATTERY/(-) M441102A-1 1 AC X
42-3 10036660 SPRING/BATTERY M441099A-1 2 AC X
42-4 10036661 SPRING/BATTERY M441100A-1 3 AC X
43 10025065 PLATE/LOWER M341268-001 1 AM X
44 10025066 PLATE/LOWER M241302-001 2 AP X
45 10187095 FDD 702D-6238D-050017 1 CX C
46 10130438 CONNECTOR AMP-2P-120-M735 1 AI C
47 10130439 CABLE/FDD CA-X125-070-A13 1 AW C
48 10025048 BLACKET L/FDD M341272-001 1 AD C
49 10025046 BLACKET R/FDD M341273-001 1 AD C
Accessories
- 10229891 AC ADAPTOR AD-12UL-TC3(D) 1 C For US
- 10247805 STAND/MUSIC M141071-006V01 1 X
- 10055632 BATTERY GP13A0-9S2 3 BG C Except EU/US
N - 10247807 LABEL/RATING M341007-063V01 1 X
- 10248108 CD ROM IDES50CDROMWL1A 1 C
N - 10247868 FLOPPY DISK WK3800FDWL1A 1 C
Notes : Q - Quantity per unit
R - Rank
