-20-
E. MODULE LSA-M (REFLECTOR) E-1. Unscrew
one screw (S9) and remove the LSA-L cover.
E-2. Unscrew one screw (S7).
located around her. NOTE: If
the cover is difficult to remove, use a tool such as tweezers.
MODULE LSA-M
NOTE: When removing the LSA-L cover, make sure it does not come into contact with components
Screw (S9)
Screw (S7)
XJ-A240/A245
COVER LSA-L
