XJ-A240/A245
• Securely fasten the rear panel and power cable entry.
NOTE: When routing the speaker wires, keep the screws and connector away from the wires and secure the wires in place
with tape.
<ASSEMBLY NOTES: COVER B>
• Route the speaker wires as shown in the figure below.
Salary PWB-1
Tape
-34-
speaker wires
