34
You can output audio to an amp speaker or another device instead of using the projector’s built-in
speaker.
Under initial projector default settings, audio is output from the projector’s built-in speaker. To output
audio using another device, connect as shown below and then change the Setup Menu “Option
Settings 2 3 Audio Out” setting to “Line”.
You can also configure settings so that audio input to the projector continues to be output
from the AUDIO OUT terminal even while the projector is in standby (projector turned off, but
being supplied with power) (An XJ-UT Series model, XJ-S400UN, or XJ-S400WN only). See
“Option Settings 2 3 Standby RGB/Audio” (page 65).
Outputting Audio from the Projector to Another Device
XJ-UT Series XJ-F Series XJ-S Series
Projector Terminal Connection Cable Other Device Terminal
AUDIO OUT Audio In terminal
Audio cable
Stereo mini jack
To Next Page
