Casit KEQS08 - 2.2 Description of the electrical connection

230 Vac 1 Electrical power supply 230 Vac 50 Hz
230 Vac 2 Electrical power supply 230 Vac 50 Hz
Signal Light
3
Output for 230 Vac signal
or courtesy light maximum power 40W
4
MOT common 5 Output for connection of COMMON motor pole
MOT close 6 Output for connection of CLOSING motor pole
MOT open 7 Output for connection of OPENING motor pole
+ Antenna 8 Input for antenna signal
Common 9
Common for all inputs:
services, safety devices, coaxial cable, 12 Vdc
Common 10
+ 12Vdc 11 Output +12 Vdc maximum current 50mA (positive)
Stop 12 STOP input
PHOTO 1 13 Input for photocell 1 (intervention only when closing)
Lso 14 Input for opening limit switch
Lsc 15 Input for closing limit switch
Start 16 Input for bistable START
Pedestrian 17
Input for bistable partial PEDESTRIAN opening
(same setting as START)
24Vac 18 Output 24Vac (See Par. 2.10 & 2.11)
+ 24Vdc / 24Vac 19 Output + 24Vac/dc (See Par. 2.10 & 2.11)
- 24Vdc 20 Output - 24Vdc (See Par. 2.10 & 2.11)
PHOTO 2 21 Input for photocell 2 (intervention in opening and closing) DIP6A
Electrical lock 22 0 Vac Electrical lock (See Par. 2.13)
12 Vac 23 Out 12 Vac Electrical lock
Dry contact 24
“Dry” contacts for light or photocell TEST
or fl ashing light without intermittence circuit board
Dry contact 25
+5 Vdc 26 power supply of the Encoder
Signal for encoder 27 Signal for encoder
-5 Vdc 28 power supply of the Encoder
