CassidaPRO Zeus: Service Manual
2018 Cassida Corporation. All rights reserved.
Rev: 09/05/2018
cassidapro.com/partner/
RECOMMENDED SPARE PARTS APX 1
32 1E09513A 1 PBA_ENCODER
33 1E09517A 1 SMPS
34 1E10001A 1 LCD_240X320_2.8_80_I/F
35 1E10002A 1 CIS
36 1E20003A 1 MR_HEADER_60mm
37 1E20004A 1 MR_HEADER_30mm_L
38 1E20005A 1 MR_HEADER_30mm_R
39 1M10006A 1 DUST_DRAWER
40 1A20035A 1 DB_SENSING_MODULE
41 1M10035A 1
SUPPORTER_STACK_WHEEL
(To assemble stacking wheelmodule)
42 1M10038A 1 SWING_SELECTOR
43 1M20011A 1
CLIP_MG_HEAD
(To assemble HG head)
44 1M20014A 2
BRACKET_MG
(To assemble magnetics)
45 1M30001A 2 ROLLER_R_PINCH
46 1M30002A 2 ROLLER_EXIT_PINCH
47 1M30003A 2 ROLLER_F_PINCH
To Next Page
