CassidaPRO Zeus: Service Manual
2018 Cassida Corporation. All rights reserved.
Rev: 09/05/2018
cassidapro.com/partner/
RJ45 (LAN)
1) CONNECTION WITH A PC
Required cable: LAN Cable (LAN PC Port)
• Communication data format: TBD. API manual available upon request.
USB-A
1) CONNECTION FOR USB EXTERNAL STORAGE
Connection for USB external storage
• USB memory file system must FAT32 format.
USB-B
1) CONNECTION WITH A PC
Required cable: USB-B – USB-A (USB-A PC Port)
• Communication data format: API manual available upon request.
• Requires Windows Driver (linux-cdc-acm.inf) which can be provided by
Cassida PRO Tech Support upon request.
Example of USB-B – USB-A cable:
1.4.3.
1.4.4.
1.4.5.
