CHANNEL FUNCTION pin Colour
CN2 Door 5 nc
6 Blue
7 Brown
CN3 Ambient probe 1 black
2 black
3 nc
4 nc
CN4 12 nc
13 nc
Compressor / condenser fan 14 Brown / black
15 Blue / black
line 16 blue
17 brown
CN5 Evaporator fans 8 Brown
9 Blue
10 Nc
11 Nc
CN6 Nc
CN7 keypad
