It is important to ensure cable termination is neat and tidy into the terminal blocks
to ensure there is no risk of active conductors migrating to earthing screws.
The recommended cable profile is show below.
2.1 – Cable termination into the device
20mm
9mm
• Ensure cables are position so that no long term load is applied to
terminal blocks.
• Ensure all terminal block screws are screwed in tight, even the
ones that are not used.
