Check Method of Causes
Explanation Figures
Repair Method
Cateye Ergociser EC-5000 Service Manual
17
Improper Display on Control Unit
T-5
Improper Display on Control Unit
T-5
In case of the problems stated below, check should be made by re-
ferring to corresponding “Symptoms of Problems & Causes.”
· No display of cadence is possible even when the pedal is ro-
tated. (See T-2.)
· No display of pulse rate is possible. (See T-3.)
· No display of heart rate is possible. (In the case of the Wire-
less Chestbelt Pulse Sensor Kit is used.) (See T-4.)
[1] The displayed language is different from the one described in the
Operating Instructions.
ⓦ You need to take actions as specified in the repair method
(a) described at the right.
[2] Pulse rate, etc. can be displayed, but corresponding graphs can-
not be displayed.
ⓦ You need to take actions as specified in the repair method
(b) described at the right.
[3] Other problems (including breakage of display unit, and unclear
display quality)
ⓦ You need to take actions as specified in the repair method
(c) described at the right.
(a) Operate the select switch on the back of the con-
trol unit.
(See [ES-9: Replacing the Control Unit]:
ASSEMBLE: 2.)
(b) Replace the control unit.
(See [ES-9: Replacing the Control Unit].)
(c) Replace the control unit.
(See [ES-9: Replacing the Control Unit].).
To Next Page
