Cateye Ergociser EC-5000 Service Manual
4
EC-5000
Name of Parts
Caster Pipe
Levelling Knob
Rubber Stopper
Chain Joint
Sprocket A
Shaft Set A
Pedal Chain
Power Suplly Board
Spring
Name of Parts
Caster
Leg Cover
Linkstep Set
Coad Clip
V-Belt Tension Pulley
Frame
V-Belt
5P Cable
Coad Clip
Spring Pully Set
2P Cable
(Inlet Metal Base Set)
Consolepost Fastening Bolt
(cap bolt M8 x 25)
CDC Sensor Cable
Pully A
3
Crank Nut
t
Hexagonal Nut M8-3
e
Spring Washer 6
Plain Washer 6-22-1.6
Hexagonal Nut M6-1
6
9
w
Bolt (+) M6 x 16
i
Bolt (+) M6 x 45
y
Hexagonal Nut 10-1
r
Tapping Screw(2) 4 x 12
5
Axle & Nut Set (R/L)
o
EC-5000 Pully B Set
