Cateye Ergociser EC-5000 Service Manual
5
Name of Parts
5P Cable
Frame
Pully A
Sprocket B
Spring
Spring Pully Set
Copper Plate
Caster
CDC Sensor Cable
CDC Sensor Set
Idler Set
Idler Spring
Link Step Set Accelerating
Chain
Rubber Stopper
Pedal Chain
Step
Step Stopper
Shaft Set A
Sprocket A
Chain Joint
Workload Unit
Solenoid Coil Fixing Metal Base
Solenoid Coil
Cap Bolt M6 x 22
1
Crank Nut
t
Plain Washer 6-13-1.0
E-Ring 4
8
q
Bolt (+) M6 x 12
u
Tapping Screw (B) 4 x 16
4
Cap Bot M8 x 20
Spring Washer 8
Plain Washer 8-17-1.6
2
7
0
