Caton NVE 902 - 2 Front Panel Control; 2.2.1 Basic Operations

NVE902 H.264 HD Network Encoder User Manual
2 Front Panel Control
2.1 Power up
Power up NVE902, OLED screen will display as follows:
P Lock>>>>>>>Unlock
V 192.168.050.016
A
E Lock>>>>>>>Unlock
P ← Menu →
V 1.1 Device IP Address
A 192.168.050.016
E
Starting
Loading
Power On
Starting
Completed
Screen Locked
2.2 Control Method
2.2.1 Basic Operations
Through the NVE902 front panel, user can do the following operations:
(1) Unlock: Slide the “Select” button or “Adjust” button from left to right to
unlock the OLED screen. The screen will be locked if there is no operation
over 1 minute.
(2) Enter: Press the “Enter” button to enter the submenu or save the modifications.
(3) Esc: Press the “Esc” button to return to the upper menu or cancel the
modifications.
(4) Select: Press the “Select” button to select the menu or select the position of
parameters.
(5) Adjust: Press the “Adjust” button to select the option or modify the parameter
value.
Steps to configure parameters through front panel:
Slide the “Select” button to select the menu, press the “Enter” button to enter the
edit mode:
5
