PRODUCT OVERVIEW
1. Door
2. Control panel
3. Handle
4. Shelves
5. Adjustable feet
6. Vents
7. Door reversal left top hinge
8. Door reversal left bottom hinge
9. 1 x Humidity reservoir
UNIT PARTS & SPARE PARTS
Before installation, check that all parts detailed in the product overview are present. If any parts are missing,
please contact the Product Care Customer Service team.
POSITIONING & INSTALLATION
• This appliance can be installed as a freestanding or a built in unit. The clearances shown in the below drawing
should be followed for both types of installation.
• Avoid damaging the product during installation, positioning of the appliance requires two people in order to
avoid injuries or damage to the appliance.
• Your appliance should not be located in direct sunlight or exposed to continuous heat or extremes of
temperature (e.g. next to a radiator or boiler). If this is not feasible, then you should install an insulation plate
between the appliance and the adjacent heat source.
• You should check whether there is an electrical socket available, which will be accessible after your appliance
is installed.
• Place the appliance flatly and firmly on a solid base. The appliance is fitted with adjustable feet, which should
be used to level the appliance.
• Be sure to leave enough space for the opening of the door, to avoid damage to the appliance or personal
injury
• If installing as a built in unit the aperture size has to be a minimum of (H)875 x (W)600 x (D)600mm. The depth
dimensions in particular must be observed.
