C10QM/C20QM EVK User Manual
www.cavliwireless.com
2.3 Pin Layout
2.3.1 P1 Pinout – C10QM/C20QM
Pin No.
Pin name
Pin No.
Pin name
1
P_SYNC
2
DBG_RX
3
P_IN
4
DBG_TX
5
P_OUT
6
U3_RX
7
P_CLK
8
U3_TX
9
P_INT
10
U3_CTS
11
MOSI
12
U3_RTS
13
CLK
14
U4_RX
15
MISO
16
U4_TX
17
CS
18
3.3V
19
GND
20
NC
21
SCL
22
NC
23
SDA
24
1.8V(VCCB)
25
BOOT
26
GND
27
GND
28
ADC1
29
ADC2
30
GND
31
STATUS
32
POWER ON
33
UIM_SEL
34
RES OUT
35
RESET IN
36
GPIO24
37
WWAN
38
GPIO25
