CBE Avida PC220-KT - Specific Connections; User Connections; Waste Water Tank Probe; Electronic Waste Water Probe

CONNECTIONS
FUSE
8
6
9
10
FUSE
3
2
1
4
6
WASTEWATERTANKPROBEWITHSCREWS(RE-VI)
Toconnecttothewastewatertankprobewithscrewsortotheelectronicwaste
watertankprobe.
NB:Donotconnectbothtypesoftankprobes!
DRINKWATERTANK
Toconnecttothedrinkwaterelectronicprobe.
1) +exit AUX(direct“B2”).
2-3) +exit3wayfunctionfridge/ AES.
4) +exitelectricstep(direct“B2”).
5-6-8-9)+exitgasusers(fridge,kkitchen,etc...)(direct“B2”).
1) +exitRH,itdependsonthemainbuttonON/OFF.
2) +exitspare,itdependsonthemainbuttonON/OFF.
3) +exitMultimedia,itdependsontheMultimediabutton.
4-5) +exit TVsockets,itdependsonthemainbuttonON/OFF.
6) +exitRH,itdependsonthemainbuttonON/OFF.
USERS
USERS
1
4
7
2
5
8
3
6
9
1
4
2
5
3
6
1
2
1
2
3 4
RED
WHITE
BLACK
BLACK
20
24
22
19
FUSE
7
12
11
13
14
1) +exitheater/HWS,itdependsonthemainbuttonON/OFF.
2) +exitwaterpump,itdependsonthepumpbutton.
3) +exitawninglight
4-5-6) +exitlightscircuit“A”,itdependsonthelightbutton.
7-8-9) +exitlightscircuit“B”,itdependsonthelightbutton.
USERS
1
4
7
2
5
8
3
6
9
WHITE
21
1
2
3 4
BLACK
23
ELECTRONICWASTEWATERTANKPROBE(RE-EL)
NOTCONNECTED
WHITE
18
1
9
8
16
CONTROL PANEL
Toconnecttothe16polesconnectorofthecontrolpanel.
SIGNALS(OPTION“A”)
1) +inputsignalcontactkeyenginestarting.
2) +inputsignal“S”netcomingfromthebatterycharger.
SIGNALS(OPTION“B”)
1)N.C.
2) +inputsignalcontactkeyenginestarting.
1) +inputsignal“S”netcomingfromthebatterycharger.
2)N.C.
1
2
1
2
1
2
BLACK
WHITE
RED
WHITE
26B
25
26A
GB
ENGLISH
GB
11
