CBE Avida PC220-KT - Main Visualizations; Display Icons and Symbols; Digital Display Information; Functions

GB
ENGLISH
GB
6
1)
2)
3)
4) .
5)
6)
7)
8)
9)
10)
11)
12)
It shows that the minimal voltage device is switched on.
It displays that the 240V battery charger is on.
It displays the batteries’ paralleling when engine is on.
Fresh water tank status display.
“B2” leisure battery status display.
It shows the fresh water tank test, the blinking indicates the empty tank alarm.
It shows the leisure battery (B2) test, the blinking indicates the discharged battery alarm
that
It shows the car battery (B1) test, the blinking indicates the discharged battery alarm.
It shows the unit of measure
It indicates that the engine is on
It shows the waste water tank test, the blinking light indicates the waste water tank is full
Digital display of the clock and of the required test.
and display kind.
2 3 4
6
5
7 8 9 10
11
12
1
MAINVISUALIZATIONS
FUNCTIONS
CHASSISBATTERY ALARM(B1)
CHASSISBATTERY RECHARGE(B1)
LEISUREBATTERY ALARM(B2)
Whenthechassisbatteryvoltagedropsdownto12V,theMotorBatteryDischargealarmgoesonand
thesymbolref.10startsblinking. Alarmgoesoffwhenthevoltagegetsover12.5V.
Withbatterycharger:anelectronicdeviceallowstherecharge(max2A)ofchassisbattery(B1).
Priorityisgiventoleisurebattery(B2)charge.
Whenleisurebatteryvoltagedropsdownto11.5VtheLeisureBatteryReservealarmgoes
automaticallyon,thesymbolref.8startsblinkingandyouhearashortbeep.
Whentheleisurebatteryvoltagedropsdownto10.5V,theLeisureBatteryDischargealarmgoes
automaticallyon,thesymbolref.8startsblinkingandyouheartwoshortbeeps. Alarmsgooffwhen
thevoltagegetsover12.5V.
