CBE Avida PC220-KT - Leisure Battery Charge B2; Minimum Voltage Control; Electronic Battery Separator; Amperemeter Function

GB
ENGLISH
GB
7
LEISUREBATTERY CHARGE(B2)
a)
b)
c)
MINIMUMVOLTAGECONTROL (BATTERY PROTECTION)
ELECTRONICBATTERY SEPARATOR
DIGITAL CLOCK
Through engine alternator: through separate relays when engine is on. The ignition electronically
controls the relays: parallel, fridge, awning light, etc.
Trough240Vmainspowerthroughbatterycharger.
Troughsolarpanel:throughsolarchargeregulator.
The electronic battery protection device cuts off the 12V fuses when leisure battery reaches 10V and
disables: pump, lights, Multimadia and stove.
Symbolref.1isthevisualalarmsignal.
Itispossibletoreactivateallfusesforoneminutebypressingtheon/offbutton(ref.06oncontrol
panel).
Thecontrolpanelautomaticallyturnsoffwithavoltagelowerthan9.5V.
Fusesareautomaticallyreactivatedwhenvoltageisgreaterthan13.5V.
Thisdevicedoesn’tcontrolthefunctions:fridge,stepandtheauxiliaryexitDIR.
Anelectronicdevicecontrolledbytheignitionswitchesonthebatteriesparallelwhenthechassis
batteryvoltageisover13.5Vandswitchesoffwhenengineisofforvoltageislowerthan12.2V.This
deviceoperatesonlyiftheB2leisurebatteryisconnected.
Thisdevicecontrolstherelaysofthefusesdependingfromexitsimulating+OUT D+(3wayfunction
fridge,awninglight,antennamotion,etc.).
Tosetclocksee“SETTING”.
AMPEREMETER
BROKENFUSE ALARM
TheamperemeterisinsidetheDS520-ANmodule.
-Itmeasuresthecurrentoftheleisurebattery,users’ consumptionandrechargethroughbattery
charger,enginealternatorandsolarpanels.
-Measurementrangeis:-40A ÷+40A.
-Measurementiscarriedoutasdifferencebetweencharginganddischargingcurrents:apositivevalue
indicatesachargingcurrent,anegativevalueindicatesadischargingcurrent.
Tomeasurethechargingofasolesource(batterycharger,alternatororsolarpanels),turnoffall
itemsandotherchargingsources.
Tomeasuretheconsumptionofasoleuser,disconnectallchargingsourcesandturnoffallunused
items.
UndereachfuseispositionedaredLED.
ThelightingoftheLEDsignalsthatthefuseisbrokenanditisnecessarytoreplaceitwithanotherfuse
withthesamevalue. Thealarmisactivatedonlywhenthecontrolpanelisonandtheuserrelatedto
thefuseisswitchedon.
NOTE:beforereplacingthefusefindouttheproblemthatdeterminedtheinterventionoftheprotection
(blownfuse)andfixit,itmaybenecessarytohaveaqualifiedtechnicianassist.
FUNCTIONS
