CBE PRM350 - Legend; Connections

14
LEGEND
CONNECTIONS
1) FLOAT-OK indicates the charge
maintenance stage at constant voltage .
Green led :
a
2) CHARGEYellow led : indicates that
photovoltaic modules are charging the battery
( >0.1 A).
the
with charge
3) SOLAR ON indicates that the
regulator is on (without sunlight, the regulator
turns off automatically).
White led :
4) ALARMRed led : indicates
(wrong connection) of photovoltaic modules
and/or leisure battery.
a reverse polarity
the
the
5) Cooling fan: with variable automatic adjust
ment.
-
2) Solar signal output (12V - max 50 mA)
1) /
3) /
4) /
SOLAR SIGNAL (with CBE systems only)
6)
CL-BUS nodes connection.
CL-BUS CONNECTION
8)
Connector for connection to the CBE test panel model PT 2.74
PT 2 CONNECTION74
7)
EN
1
5
2
3
4
6
7 8 9 10
11
