4
- The Mains AC socket from where the PBX is given 220 V AC, should be separately made by taking direct connections
from the MCB Box and no other Electrical appliance should be connected on this point.
. Terminologies Used .
JUNCTION LINES - Telephone Lines provided by the Department of Telecom.
EXTENSION LINES - Extension Lines mean the EPABX extension lines.
. Programming the PBX .
To program most of the feature mentioned in this manual, programming Password is to be entered from any of the first 8
extensions (6001, 6002, 6003, 6004, 6005, 6006, 6007 & 6008) through the following command:
#0000 (Here, 0000 is the default Password)
In case of any mistake while programming, dial to reset or else keep the Handset down and pick up again.
Whenever a correct input is entered, PBX will give one single acceptance tone and when wrong input is given, it will give
three tones.
. Alarm
An Extension user can set an Alarm, when alarm time matches current time of PBX, extension will ring. Once extension is
offhooked ring will stop and alarm is cleared.
To set Alarm Dial: #85 A/P HH MN #
Where HH= Hour (01-12)
MN= Minute (00-59)
A/P= 0 for AM, 1 for PM.
To clear Alarm: # 85 #
. Allowed Table .
Numbers to be allowed to extensions whose L = 0, are to be defined in this table. For value of L refer “Junction Dialing
Controls”.
This table has 16 Locations.
Procedure: Dial #0000 + 43 QQ ABCD#
Where QQ= 01 to 16 (16 Locations of the Table)
ABCD= The starting 4 digits of the Tel numbers to be allowed to extension.
For less than 4 digits, dial # at the end of digits.
To clear this Table: Dial #0000 + 43 #
To clear a particular location of this table: Dial #0000 + 43 QQ #
. Auto Call Back .
From Busy Junction Lines
To get a call back when any of the busy Junction lines get free, following is the procedure:
Dial 0/8
Get engaged tone
Dial #
Keep the handset down.
As soon as any one of the busy Junction lines gets free, the Extension will ring. It will ring once and the user can pick
handset within 10 secs to get connected to the Junction line.
From Busy Extensions
To get a call back when any of the busy Extension gets free, following is the procedure:
Dial Extension Number
Get engaged tone
Dial # and Keep the handset down.
As soon as the busy Extension gets free, the called and calling Extensions will ring simultaneously. User can pick
handset within 10 secs to get connected to each other.
. Auto Call Disconnection .
Selected extensions can be programmed to disconnect Out going Junction call after talking for a set time.
Procedure: Dial #0000 + 6 NNNN TT #
Where, NNNN= Last 3 digits of the Extension Number.
TT= 01 to 99. Time in minutes after which the Junction call is to be disconnected.
Note: In default there is no restriction.
: This auto call disconnection is not applicable on incoming Junction calls.
To cancel this feature: Dial #*0000 6 NNNN 00 #
. Auto Attendant Operations .
When the PBX is operated in this mode, the Junction caller gets a welcome message.
By default, built-in auto attendant is called “Internal”.
