CCL COX-416S - Introduction; Installation

Flexible Numbering
Hold Music (11 Types)
Hold Music - Volume Setting
Hot Line to Junction
Hot Line to Extension
Junction Access During Power Failure
Junction Access Codes / Change
Junction Access in Circular / Sequential Mode
Junction Access Control
Junction Dialing Controls
Junction Call Hold + Transfer + Making multiple calls
Junction Dialing Delay Time
Junction Grouping
Junction Line - FLASH
Junction Line Ring Assignment
Junction Line - Enable / Disable
Junction to Junction Forwarding (Optional)
LCR (Least Call Routing) - Manual
Memory Dialing
Operator Extension Setting
Password
Redial
Remote Programming
Resetting the PBX programming
Ring Time Settings
Troubleshooting
Technical Specifications
Terms of Warranty
NOTE-Copper Connections reserves the right to alter equipment specifications and description contained herein and
makes no commitment to update or keep current the information herein. All information herein is subject to change
at any time without notice. No part of this publication shall be deemed to be part of any contract or commitment
whatsoever.
- Product specifications and features are subject to changes without prior notice due to our constant endeavor to improve
the product.
- All features mentioned in this manual are not part of standard systems. Some features need optional
hardware/software up-gradation.
- Not every feature in this manual is likely to have been installed in your system or extension.
. Introduction .
All Junction lines of the PBX are
Disabled in default. To enable them refer heading “Junction Line - Enable / Disable“
Model
Junction Lines
Extensions
Door Phones
Interface
Door Locks
Interface
308 S
Numbered as 1
to 3 having
access code as
#11, #12 & #13
- Numbered as 601 to 608
- 602 is the Operator.
- Programming can be done from
601, 602, 603 & 604
2
1 Door Phone
consumes 1
Extension port.
2
2
nd
Lock
Operation is
OPTIONAL
416 S
Numbered as 1
to 4 having
access code as
#11, #12, #13
& #14
- Numbered as 601 to 616
- 602 is the Operator.
- Programming can be done from
601, 602, 603 & 604
2
1 Door Phone
consumes 1
Extension port.
None
432 S
Numbered as 1
to 4 having
access code as
#11, #12, #13
& #14
- Numbered as 601 to 632
- 602 is the Operator.
- Programming can be done from
601, 602, 603 & 604
2
1 Door Phone
consumes 1
Extension port.
2
. Installation .
Cabling
- All cables of the EPABX should be at least 6” away from the electrical cables.
- They should be at least 12” away from the area of high frequencies like tube light
