cctv camera pros MON-7HD - Page 11

Page.6.
20
The power indicator: it lights green while the tester is powered on by the adapter
Top interface
Bottom interface
21
Visible red laser source emits Interface (Optional)
22
DC12V2A power output , for provisional DC power supply
23
HDMI IN (Optional )
24
CVBS IN/AHD /TVI/CVI Coaxial interface /（BNC interface）(AHD /TVI/CVI (Optional) )
25
Video signal output（BNC interface）/ cable tracer interface
26
Optical power meter interface (Optional)
27
LED lamp
28
RS485 Interface: RS485communication for the PTZ
29
SDI input (BNC interface) ( Optional)
30
TDR cable test interface (Optional)
