Installation "C" By Using Housing Unit
(figs. 29, 30, 31)
• Remove the single oven shelf, if tted, as indicated in gure 29.
• Remove the upper cross member support as indicated in gure 30.
• Cut the bottom of the housing as indicated in gure 30.
• Screw oven base housing to adjoining cabinetry by suitable screws (not supplied) as indicated in
figure 31.
• Check the position of the cabinet legs to ensure the cut-out does not interfere with the legs support.
Otherwise the cabinet may have to be removed as in INSTALLATION TYPE "B".
• Mount the 2 (two) metal supports “B” (supplied with the appliance in a separate kit) as indicated in
Figs. 31).
• Build in the double oven making it slide on the metal supports “B”.
