12
be at least the minimum height specified).
5. Place the chimney section over the body assembly, as shown in fig
8.
6. With the help of another individual, raise the whole assembly to the
ceiling and fix securely in place using four screws appropriate for
the wall plugs inserted in step 2. Ensure that the supporting ceiling
is strong enough to take the weight before releasing the extractor.
7. Connect the ducting to the extractor vent outlet, securing it in place
with a cable tie, duct tape or other suitable means.
8. Finally, raise the inner section of the chimney to the ceiling and
secure in place using the two small screws supplied
9. Note that the electrical connection to the extractor should not be
located inside the boundaries of the chimney. This is especially
important if the extractor is to be used as a recycling device.
There should be an isolation switch so that the extractor can be
disconnected from the mains electrical supply after installation.
The metal casing of this appliance has been coated with a
preservative to protect it during transport and storage. This should
be removed during installation by using a non-abrasive stainless
steel cleaner. Always follow the instructions given with the cleaner
being used.
