18
4. IF THE EXTRACTOR IS TO BE USED AS A RECIRCULATION
DEVICE (filtering the air before recycling it into the kitchen) then
the vent diverter needs to be fitted. Fit the diverter to to the upper
cage section (Fig. 17) and then connect the ducting to it.
5. Connect the extractor to the mains electrical supply (if safe to do
so). Refer to pages 9 and 10. Secure the chimney sections to the
upper cage section using the four supplied screws (F in Fig. 18).
Fig. 17
Fig. 18
