20
2. Position the hob seal, as shown in the diagram below (Fig. 14), ensur-
ing that the ends meet without overlapping. Do not use silicone type
sealant.
3. Secure the hob to the worktop using the fixing brackets and screws
supplied, as shown in the following diagram (Fig. 15). Remove any
excess sealant after tightening the brackets.
400mm
750mm
Fig. 12
Fig. 13
Fig. 14
Fig. 15
>61.5mm
150mm
150mm
557mm
477mm
3cm
4cm
