Key to Figs 2, 3 & 4
Gas burners:
1. Triple burner 3.5kW
2. Rapid burner 3.0kW
3. Semi-Rapid burner 1.75kW
4. Auxiliary burner 1.0kW
Control panel:
5. Front left burner control knob
6. Back left burner control knob
7. Back right burner control knob
8. Front right burner control knob
These appliances are class 3
hg6320
Fig. 4
3
1
4
3
5 6 7 8
