20
2. Take the supplied seal and cut it
to length so that all four edges of
the glass are covered by the seal.
Remove the white backing and stick
the seal strips in place.
3. Attach the four supplied fixing clips
to the sides of the hob, as per Figs.
8 and 9. Fig. 9 is a view of the hob
within the worktop and is intended
to illustrate which way up the clips
should be fitted.
4. Make sure that the worktop is clean
and dust free and insert the hob
into the cut-out opening. Press the
hob firmly into place so that the seal
connects with the worktop (Fig. 6).
1 - Worktop
3 - Induction hob
321
2 - Hob seal
Fig.6
Brackets
Screw
Fig. 8
nim
06
nim
268
500
60
Cut-out
Fig. 7
Fig. 9
HobWorktop
Hobtop
