30
Fig.6
400mm
600mm
Do not install the hob above an oven without ventilation.
m056
nimm
mm
82
mm056
nim
30mm
mm
21
If fitting a cooker hood above the hob:
If a cooker hood is to be installed above the hob, the height of
the hood above the hob must be at least 600mm (650mm is
recommended) (Fig.6).
If the instructions supplied with the hood dictate that the hood must
be installed at a height greater than 600mm, then that height is the
minimum required.
