18
Fig.3
Fitting the Hob
Unpacking the hob:
Take care not to lose or mishandle any
parts.
Fitting position of the hob:
This appliance must be installed a
minimum of 50mm from any back wall
and a minimum of 180mm away from
any adjacent vertical surfaces, e.g. a
tall cupboard end panel. This may
be reduced to 100mm if the adjacent
surface is resistant to fire (tiles or steel,
for example). These dimensions are
shown in Fig.7.
Ventilation requirements:
This appliance must be installed to
allow air to flow freely to the air intake
and from the air outlet. An air gap of
20mm is recommended immediately
below the hob.
Failure to allow sucient ventilation
could cause damage to the hob and
constitutes incorrect installation, which
is not covered by the warranty (Fig 5).
Ⓐ
Ⓑ
30 mm
51 mm
30 m
m
51 mm
30 mm
51 mm
40 mm
~ 2 mm
~
2
m
m
Fig.4
