CDA PZ 10/2 User Manual

6
Control panel
Fig. 3
A
U
T
O
225
250
200
175
125
150
75
100
50
225
175
125
75
250
200
150
100
50
98
7
65 1032111
Control panel - Controls description
1. Front right burner control knob
2. Rear right burner control knob
3. Central rear burner control knob
4. Central front burner control knob
5. Rear left burner control knob
6. Front left burner control knob
7. Multifunction main oven switch knob
8. Multifunction main oven thermostat knob
9. Electronic programmer (main oven only)
10. Conventional oven thermostat knob
11. Conventional oven switch knob
Pilot lamps:
12. Main oven thermostat indicator light
13. Conventional oven thermostat indicator light
4
12 13
Please note: This appliance incorporates a safety cooling fan which you will hear
operating whenever the oven or grill are in use. The cooling fan may also operate when
the oven is switched off.
