CDA SK510 Single - Oven Door

24
Oven Door
Removing the Oven Door
The oven door can easily be removed
as follows:
• Open the door to the full extent (Fig.
5).
• Open the lever “A” completely on the
left and right hinges (Fig. 6).
• Hold the door as shown (Fig. 9).
• Gently close the door (Fig. 7) until left
and right hinge levers “A” are hooked
to part “B” of the door (Fig. 6).
• Withdraw the hinge hooks from their
location following arrow “C” (Fig. 8).
• Rest the door on a soft surface.
• To replace the door, repeat the above
steps in reverse order.
Fig. 5
Fig. 7
Fig. 8
B
A
Fig. 6
C
Fig. 9
A
B
C
