CD42 Pipeline Pig Location & Tracking System
Page 59
The CD42-T2
Typical transmission range through pipe of approximately 50 feet
Recommended for use in pipelines 30” to 60” in diameter
Guaranteed minimum 375 hour battery life (15½ days)
Pressure rated to 2,500 PSI [170 bar]
Cylindrical dimension of 13” X 4.4” [330mm X 112mm]
Powered by 6 C-Cell alkaline batteries
The Antenna
Weighs 6.0 lb.
Shoulder strap included
Receives open air signals to a distance of 50 feet.
Waterproof
6 ft. cable included, 20 ft. cable optional
