Enclosure Side View
Enclosure Door
Nut
Spacer
Spacer
Screw
Spacer
Install the wall tamper switch using the supplied bolts and nuts as shown in the following picture.
Install the tamper switch
plastic spacer on the back
at bottom left side of
the box as show in
the following picture.
