The ATRIUM 2-Door Controller provides a 10/100Mbps Ethernet port to allow direct connection from a local
PC or interconnect to an existing LAN/WAN. Connect the Ethernet 10/100 Mbps port of the ATRIUM 2-Door
Controller to a LAN or WAN network using an UTP cable (maximum 100m (300ft)).
READER 2
INPUTS
LOCAL
BUS
READER 1
BATT.
POWER
SUPPLY
BELL
DOOR 2
12V Z6 GND Z7 Z8
C1
NO1 NC1
C2
NO2 NC2
GND Z9 Z10
12V Z1 GND Z2 Z3 GND Z4 Z5
AC22
2-Door Controller
Ethernet @ 10/100 Mbps
Maximum 100m (300ft.)
