3] PACKAGE CONTENTS
This chapter details how to install and setup the ATRIUM 2-Door Controller.
The 2-Door Controller contains:
• One 2-Door Controller module in its cabinet with connection diagram label
• AC power cord
• Metal Box kit:
• Installation kit:
If any item is missing, please notify your distributor immediately.
Wall Switch
and a white
wire (115mm)
with a log at
each end
Wall Switch
Spacer
Door Switch
and 2 white
wire (350mm)
with a log at
one end
Door Switch
Support
Metal box
screw
Metal box
lock and key
1 2 each 1 1 1 4 1
for backup
battery
(400mm)
1K Resistor 2.2K Resistor
Diode 1N4007
for the door
strikes or
locks
Installation
Kit
1 pair 22 10 2 7
