CDVI PROFIL100EC - DEFAULT VALUES AND BASIC CONFIGURATION; Initial System Defaults; Resetting Codes; Setting Code Length and Master Code

EN
PROFIL100EC
Keypad PROFIL100EC
5cdvigroup.com
A. Reset master code
and user codes
1. Enter the master code twice
(1 2 3 4 5 defaultvaluemastercode).
2beepsareemittedtoconrmentry
in programming mode.
2. Press A6 to reset the Master Code
and the User codes.
- One beep is emitted.
- Press on A and Btoconrmreset
   ofallmemoryofthekeypad.
  -Waitfortwobeeps.   
  -Themastercodeisrestoredtoitsdefault 
value 1 2 3 4 5 and all the user codes
   aredeletedfromthekeypad.
- Once the reset is completed then the keypad
returns to a stand-by operating mode.
OR
1. Cut the power. Place the jumper on P2.
2. Put the power back.
- Wait approximately 3 seconds.
-Twobeepsareemittedtoconrmreset
   ofthekeypad.
- Remove P2 jumper.
  -Themastercodeisrestoredtoitsdefault 
value 1 2 3 4 5 and all the User codes
   aredeletedfromthekeypad.
B. Setting code length
1. Enter the master code twice.
(1 2 3 4 5defaultvaluemastercode). 
   2beepsareemittedtoconrmentry
in programming mode.
2. Press A4 to program the code length.
- One beep is emitted.
- Press 4, 5 or 6forthedigitcode.
  -Onebeepisemittedtoconrm
   programmingofthecodelength.
3. Press A5 to modify the master code.
- One beep is emitted.
- Enter the new 4, 5 or 6-digits master code.
  -Onebeepisemittedtoconrm
   programmingofthenewmastercode.
4. Press B to exit from
programming mode.
2beepsareemittedtoconrmthatthe 
keypad is in stand-by operating mode.
4 beeps indicate a data computing error.
Default values
- Without codes.
- Illumination time: 10 seconds.
- Relay release time: 1 second.
- Code length: 5-digits.
- Master Code: 1 2 3 4 5.
- Programming security time :
120 secondes.
-Codelengthforsubmastercode:
Version 1 relay
(Group 1) = AB,
Version 2 relays
(Group 2) = 13.
Audible signal:
-Thebuzzerindicatesdifferent
audible signals.
 Itcanbeturnedoffcutting
 oftheST1wireontheremote
electronics.
- 1 short beep: Keypad powered.
- 1 long beep: Data computing
in programming or access
granted.
- 2 short beeps: Enter or Exit
 fromprogramming.
- 4 short beeps:
data computing error.
Code length
- The master code and the User
 codescanbeof4to6-digits
in length.
- All the keypad keys can be used
to program a code.
- The master code CAN NOT
be used as a user code.
-TodeleteaspecicUserpinCode
replace it by 0 0 0 0ifcode
 lengthis4-digitsformator
replace it by 0 0 0 0 0ifthe
 codeisin5-digitsformat or
replace it by 0 0 0 0 0 0ifthe
 codeisin6-digitsformat.
P2 jumper:
Reset master code and user
codes
P3 jumper:
Modicationofindividual
code by the user
