SMALL PIPING CONNECTIONS FOR “RA” PUMPS
6
ALLOWABLE PIPING LOADS FOR RA2096, RA3146 AND RA3186 PUMPS
MAXIMUM FORCES ON FLANGES
FOR SUCTION FLANGE
+/-F
x
≤ 200 LBS./NOM.IN. ≤ 1.2W
+/-F
y
≤ 130 LBS./NOM.IN. ≤ 0.6W
+/-F
z
≤ 160 LBS./NOM.IN. ≤ 1.0W
F
r
= (F
y
2
+ F
z
2
)
1/2
≤ 2000 LBS
FOR DISCHARGE FLANGE
+/-F
x
≤ 160 LBS./NOM.IN. ≤ 1.3W
-F
y
≤ 200 LBS./NOM.IN. ≤ 1.2W
+F
y
≤ 100 LBS./NOM.IN. ≤ 0.5W
+/-F
z
≤ 130 LBS./NOM.IN. ≤ 1.0W
F
r
= (F
x
2
+ F
z
2
)
1/2
≤ 2000 LBS
WHERE
F = FORCE IN POUNDS
F
r
= RESULTANT FORCE
W = WEIGHT OF PUMP ONLY, IN POUNDS
RA2096 1 x 1
1
⁄2 x 6 105 278 192 91
RA2096 1
1
⁄2 x 3 x 6 115 277 265 91
RA2096 1 x 1
1
⁄2 x 8 125 278 132 91
RA3146 1 x 3 x 8
1
⁄2 195 690 340 725
RA3146 1
1
⁄2 x 3 x 8
1
⁄2 220 690 340 725
RA3146 2 x 3 x 8
1
⁄2 245 690 340 725
RA3146 3 x 4 x 8
1
⁄2 270 725 295 600
RA3146 4 x 6 x 8
1
⁄2 310 785 320 600
RA3146 1
1
⁄2 x 3 x 10 240 760 310 600
RA3146 2 x 3 x 10 275 760 310 600
RA3146 3 x 4 x 10 305 830 340 600
RA3146 4 x 6 x 10 #2 345 950 340 600
RA3186 4x 6 x 10 #1 460 2300 1850 800
MAXIMUM MOMENTS APPLIED TO A PUMP ON A FULLY BOLTED AND GROUTED BASEPLATE. LOADS ARE TO BE
APPLIED ONLY THROUGH THE SUCTION AND DISCHARGE FLANGES.
Maximum allowable forces and moments
calculated from these force equations or the
tabulated moment tables are those resulting in
a maximum of .010 inch movement of the
shaft measured at the shaft coupling when the
pump is mounted on its baseplate and that
baseplate is fully bolted to a properly
designed foundation and is fully grouted in
place. For a full discussion see API Standard
610, 5th Edition.
Pump Size Wt.-Lbs. M
X
M
Y
M
Z
Pump Only Lb.Ft. Lb.Ft. Lb.Ft.
DATA SHEET #1198F
BARRIER OIL FILL
3
⁄8" NPT, PLUGGED
BARRIER OIL DRAIN
3
⁄8’’ NPT, PLUGGED
BEARING
GREASE
RELIEF
1
⁄8" NPT,
PLUGGED
SEAL VENT,
3
⁄8" NPT FOR RA3146,
1
⁄2" NPT FOR
RA3186, PLUGGED
SEAL VENT/FILL
3
⁄8" NPT PLUGGED
PUMPAGE LEAK DETECTION,
AND BARRIER OIL OVERFLOW
PUMPAGE LEAK DETECTION,
AND BARRIER OIL OVERFLOW
RA2096
RA3146 AND RA3186
BARRIER OIL FILL
3
⁄8" NPT, PLUGGED
DISCHARGE
FLANGE
SUCTION
FLANGE
Fy
Fy
Fz
Fz
Fx
Fx
Mx
My
Mz
BARRIER OIL DRAIN
3
⁄8" NPT, PLUGGED
