- Be careful with the edges, as you could cut yourself.
- The edges are protected with polystyrene, be careful.
- During transport they may cause minor injuries or cuts.
- Take the hob and the instruction manual out of the box.
- Before assembling and installation, carefully read this instruction manual.
Step 1:
Place a towel or cloth on the worktop surface and place the hob face down on it. Fig. 4
Step 2:
- Place the sealing tape supplied with the hob to seal it on the worktop surface.
- Do not use silicone. Apply the tape to the edge of the bottom of the hob, leaving about 3
mm from the edge of the glass.
- Apply the tape all around the perimeter.
- Cut o the excess and join the two ends of the tape to match. Fig. 5
Step 3:
Secure the brackets (4 pieces) at the front and rear with screws. Place the hob in a well centred
position on the pre-cut board or worktop. Make sure that the front edge of the hob is parallel
to the side edge of the worktop. Fig. 6
Please note:
- Ventilation requirements shown in gure 7 must be respected.
- There are ventilation holes around the exterior of the hob. You must ensure these gaps are
not blocked by the worktop when placing the hob.
- Do not use a silicone sealant to seal the device. This will make it dicult to remove the hob
in the future, especially if maintenance work is required.
- When tting the hob, turn it carefully and place it gently into the recess in the worktop.
Installation guidelines. Fig. 8
- The nominal voltage of the hob heating elements is 230 V. The ceramic hob can be
adapted for single-phase operation by means of a suitable bridging in the junction box
according to the wiring diagram shown in the gure. The wiring diagram can also be found
on the junction-box cover. Remember that the connection cable must match the type of
connection and the power rating of the ceramic hob.
- The connection cable must be xed in a strain relief clamp.
Warning!
- Remember to connect the safety circuit to the terminal in the junction box.
- Before connecting the ceramic hob to the mains, it is important to read the information on
the rating plate and the wiring diagram.
