BOLERO SQUAD V 2001
47
ENGLISH
- The cable connections must be made in accordance with the wiring diagram on the bottom
of the hob.
- You must use a good quality screwdriver to carefully and completely tighten ALL terminal
screws.
- If both zones do not work when you switch on the hob for the rst time, you should double-
check that all terminal screws are tightened securely. This must be done before contacting
the ocial Cecotec Technical Support Service.
Important
- DO NOT connect the appliance to the mains using a 13 A plug and socket.
- It must be connected to a 30 A double-pole fused socket outlet, with a contact separation
of 3 mm and located in an easily accessible place next to the appliance. It must not be
placed above the appliance or more than 1.25 m from the appliance.
- The cable can be coiled, if necessary, but make sure that the cable is not kinked or pinched
when installing the hob. Do not allow the cable to come into contact with hot parts of the
appliance.
Replacing the power cable. Fig. 9
- If the power cable is damaged, it must be replaced by the manufacturer or the ocial
Cecotec Technical Support Service to avoid any potential risk.
- The power cable must be replaced according to the following instructions:
o Switch o the appliance.
o Open the terminal block located at the bottom of the hob.
o Unscrew the terminal screws securing the cable.
o The “green, yellow” earth cable must be connected to the marked terminal. It should be
about 10 mm longer than the power and neutral cables.
o The “blue” neutral cable must be connected to the terminal marked with the letter (N) -
the power cable must be connected to the terminal marked with the letter (L).
4. OPERATION
Fig. 1
Fig. 1 Icons Function
3 Upper cooking-zone selection icon
4
Upper cooking zone display: it indicates the power level, the high-
temperature warning symbol, etc.
