15. Battery cover
16. Right wheel
17. Charging socket
18. Mop
19. Left wheel
20. Bottom housing
Dust tank
1. Primary lter
2. High-efciency lter support
3. Dust tank release button
4. Dust tank bottom cover
5. Dust tank bafe
6. Dust tank upper cover
7. High-efciency lter
8. Dust tank bafe
9. Dust tank buckle
10. Dust tank upper cover
11. Dust tank lower cover
Brushes
1
4
3
2
1. Main brush cover
2. Brush
3. Main brush support
4. Main brush motor
5. Special silicone brush for pets.
