1. PARTS AND COMPONENTS
Robot:
1. Back home mode
2. Power/Automatic cleaning button
3. Network configuration
Robot and sensors
1. Laser sensor
2. Top cover
3. Back home/Power/Autocleaning mode
4. Infrared receiver sensor
5. Anti-collision sensor
6. Omnidirectional wheel
7. Charging terminals
8. Battery
9. Side brush
10. Bumper
11. Motor cover
12. Main brush: For cleaning all types of surfaces
13. Left side wheel
14. Right side wheel
15. Silicone brush: Special for pet hair
16. Jalisco brush: Specific for hard floors
17. Optical sensor: Specific for preventing the robot from bumping
Wet&Dry tank
Water compartment
1. Tank lock
2. Water inlet
3. Water tank
Dust compartment
1. High-efficiency filter
2. Dust compartment
Dust tank
1. High-efficiency filter
2. Dust tank cover
