1. PARTS AND COMPONENTS
NOTE:
The graphics in this manual are schematic representations and may not exactly match the
product.
Fig. 1
1. Start/Pause button
2. Back home button
Back home button
By pressing this button or selecting it on the app, the robot will automatically go to the charging
base.
Indicator light
- Steady orange light: low battery/back home mode.
- Flashing orange light: charging.
- Steady blue light: fully charged/standby mode/cleaning.
- Oscillating/steady red light: error.
Start/Pause button
- Hold down this button to turn the robot on or o.
- Press it to start cleaning too.
3. Anti-collision sensor. Fig. 2
Fig. 3
1. Free-fall sensors
2. Driving wheels
3. Power switch
4. Charging terminals
5. Omnidirectional wheel
6. Side brushes
7. Battery
8. Mixed tank
9. Silicone brush
Charging base. Fig. 4
1. Charge indicator
2. Remote control slot for compatible models
3. Signal transmitter
4. Charging terminals
