The name of each part
The main use and contents
①Data output terminal
The serial output of the measurement data is carried out. USB form (B type).
②Pilot Lamp During Charge
The light is switched on during charge.
The AC/DC adaptor of exclusive use is used for charge.
③AC/DC Adaptor Terminal
The plug of an AC/DC adaptor is inserted.
④Fixed Knob
At the time of measurement, a fixed thing etc. is put and a main part is fixed.
⑤Display Board
A torque value and various information are displayed.
⑥System Reset
The time of full electric discharge etc. is used when resetting a system.
⑦ON/OFF (Power) Key
It use it in ON/OFF of the power supply.
⑧CLEAR (Clear) Key
It pushes, when measurement is completed, and giving an indication zero.
When the memory data is deleted, it uses it.
It is used at the time of zero adjustment.
⑨Memory Display
/ Data Output Key
It is used when displaying the memory data saved on the main part.
It uses, when outputting the saved data.
⑩Average Display Key
It is used when displaying the maximum, the minimum,
and the average of measured value.
⑪Measurement Mode Key
It is used when changing measurement mode.
It is used for the check of the function set up
during a functional numerical value setup.
⑫Torque Detecting Element
Torque is measured in this portion. The joint for measurement is attached,
or the angle of a tool is inserted, and it measure.
⑬ Numerical Setting Mode
/ Determination Key
It is used when changing the setting numerical value of various functions.
It is used when determining a numerical value.
⑭Measurement Unit Key
It is used when changing the unit of measurement.
⑮▲Key
(UP Key)
It is used when making a numerical value increase at the time
of a functional numerical value setup.
The memory data to choose are changed (increase).
⑯▼/▶Key
( DOWN・MOVE Key)
At the time of a numerical setup, when decreasing a numerical value, it is used.
It is used when moving the place which changes a numerical value to the right.
The memory data to choose are changed (decrease).
⑰ NG Lamp
It blinks, when the yes-no decision is set up, and it is "no."
Light is carried out at the time of exaggerated torque.
⑱ GOOD Lamp
The light is switched on when the yes-no decision is set up, and it is "yes"
The light is switched on when each functional numerical value is under setup.
Display section
A Battery residual quantity
The residual quantity of an internal charge of battery is displayed.
B Measurement mode
A chosen measurement mode is displayed.
C Memory data
When a memory data is used, it displays.
D The maximum,
the minimum, and an average
When a maximum, the minimum, and the average value is used, it displays.
E Measurement unit
The measurement unit chosen now is displayed.
F Torque value
The torque value in each measurement mode and unit is displayed.
